Infectious Disease
Malaria P.f./Pan Rapid Test
Detects Pf HRP2 + Pan LDH. colloidal-gold. Specimen: WB.
| Target / Analyte | Pf HRP2 + Pan LDH |
|---|---|
| Disease / Indication | Malaria |
| Series | Infectious Disease |
| Method | colloidal-gold |
| Specimen | WB |
| Test time | 10–15 min (product-specific) |
| Storage | 2–30 °C, sealed pouch with desiccant |
| Shelf life | 24 months (product-specific) |
| Regulatory | CE (IVDD 98/79/EC) |
| OEM/ODM | Available — private label & custom panel |
Direct Answer
This rapid test detects Pf HRP2 + Pan LDH in WB to support Malaria. It is a colloidal-gold screening test — a reactive result is presumptive and should be confirmed per the intended use.
Intended Use
Detection of P. falciparum (HRP2) and Pan-Plasmodium (pLDH) antigen for species differentiation.
Clinical Context
Combines Pf-specific HRP2 with Pan LDH (detects all human malaria species) — enables Pf vs non-Pf differentiation in one device, aligned with WHO RDT guidance.
Test Principle
Colloidal-gold immunochromatography (lateral flow). The device captures the target analyte (antigen or antibody) on a membrane via labeled antibodies, producing a visible test line within minutes. Qualitative or semi-quantitative, intended as a screening/triage aid — not a replacement for confirmatory laboratory testing.
Limitations
Cannot distinguish P. vivax from P. ovale/malariae; HRP2 persistence caveats apply.
Procurement
Specimen: whole blood. Format: cassette, 25 T. CE-marked line.
Interpretation
| Result | Lines | Meaning |
|---|---|---|
| Positive | Test + control line | Target detected (presumptive positive) |
| Negative | Control line only | Below cut-off / not detected |
| Invalid | No control line | Repeat with a new device |
Common misconception
A negative rapid test does not always exclude infection — timing, specimen and pathogen load all matter. Follow up clinically where suspicion is high.
Sources
Screening results are presumptive, not diagnostic. Confirmatory testing follows WHO, CDC and national regulatory guidance — see screening vs confirmatory.
Available SKUs (this series)
| Cat. No. | Product | Specimen | Format | Kit Size | Status |
|---|---|---|---|---|---|
| IMA-401 | Malaria P.f. Rapid Test Dipstick | WB | Dipstick | 50 T | CE |
| IMA-402 | Malaria P.f. Rapid Test Cassette | WB | Cassette | 40 T | CE |
| IMPN-402 | Malaria P.f./ Pan Rapid Test Cassette | WB | Cassette | 25 T | CE |
| IMPV-402 | Malaria P.f./P.v. Rapid Test Cassette +1 variants | WB | Cassette | 25 T | CE |
Technical Evidence
| Analytical performance | Sensitivity, specificity, cut-off and precision are documented per product line in the datasheet and validation report. |
|---|---|
| Average accuracy | ≥96% (overall agreement rate, manufacturer-validated). Per-product sensitivity and specificity are documented in the datasheet. |
| Clinical performance | Evaluation data (study population, reference method, agreement) available on request. |
| Cross-reactivity | Documented per analyte — see limitations above. |
| Documents | IFU · Datasheet · Certificate · Declaration of Conformity — request below. |
Buyer Information
| MOQ | Product-dependent — low MOQ available on specialty assays |
|---|---|
| OEM / private label | Custom branding, cut-off, panel and packaging |
| Samples | Available for evaluation — request via RFQ |
| Lead time | On request |
| Documents | IFU · Datasheet · COA · Validation report · CE files · Registration support |
Related knowledge
Documentation & quotation — datasheet, IFU, certificate, MOQ and OEM/ODM options on request.
Request IFU / Spec Sheet Request Datasheet Request Certificate
Last reviewed: 2026-09-12
